PRODUCT DETAIL
specification:
| Category | Unit | Specification |
| Aoolicable for | Drop cable.Indoor cable | |
| Fiber mode | Multi mode MO1 （62.5µm）， MO2 MO3 MO4（50µm） | |
| Operation time | S | About 50(no fiber cut) |
| Insertion Loss | dB | ≤0.25 |
| Insertion Loss Typical value | dB | 0.25 |
| Return Loss | dB | ≥45 |
| Fastening strength of naked fiber | N | ≥5 |
| Tensile strength | N | ≥50 |
| Reusable | Time | ≥10 times |
| Operating Temperature | ℃ | -40～+85 |
| On-line tensile strength(20N) | dB | ΔIL≤0.25 |
| Mechanical durability(500 times) | dB | ΔIL≤0.25 |
| Drop-off test(drop-off height4m,once per direction,totally 3 times) | dB | ΔIL≤0.25 |
| Package Size | Specification Item | Value |
| 15*7.3*1.5 CM | Size(CM) | 15*7.3*1.5 |
| QTY(PCS/Box) | 10 | |
| N.W(KG/Box) | 0.017 | |
| G.W(KG/Box) | 0.02 | |
| 16*16*8 CM | Size(CM) | 16*16*8 |
| QTY(Blister Box/Girt Box) | 10 | |
| N.W(KG/Box) | 0.22 | |
| G.W(KG/Box) | 0.25 | |
| 42*27*17 CM | Size(CM) | 42*27*17 |
| QTY(Gift Box/Box) | 10 | |
| QTY(Pcs/Box) | 1000 | |
| N.W(KG/Box) | 2.5 | |
| G.W(KG/Box) | 2.9 |
