PRODUCT DETAIL

Support EPON/GPON mode and switch mode automatically

Support Route PPPoE/DHCP/Static IP and Bridge mode

Support IPv4/IPv6 dual mode

Support 2.4G&5.8G WIFI and Multiple SSID

Support SIP Proctol for Voip Service

Support CATV interface for Video Service and remote control by Major OLT

Support LAN IP and DHCP Server configuration

Support Port Mapping and Loop-Detect

Support Firewall function and ACL function

Support IGMP Snooping/Proxy multicast feature

Specialized design for system breakdown prevention to maintain able system

Support TR069 Remote Configuration and maintenance

specification:

Technical itemDetails
PON Interface1 GPON BoB（Bosa on Board）
Receiving sensitivity: ≤-27dBm
Transmitting optical power: 0~+5dBm
Transmission distance: 20KM
WavelengthTX: 1310nm, RX: 1490nm
Optical InterfaceSC/APC Connector
Design SchemeRTL9607C DDR3 256MB
Flash1Gbit SPI NAND Flash
LAN Interface4×10/100/1000Mbps(GE) and 1×10/100Mbps(FE) auto adaptive Ethernet interfaces, Full/Half duplex, RJ45 connector
WirelessCompliant with IEEE802.11b/g/n/ac
2.4G frequency: 2.400-2.4835GHz
5.8G frequency: 5.150-5.825GHz
2.4G 2×2 MIMO, rate up to 300Mbps
5.8G 2×2 MIMO, rate up to 867Mbps
CATV InterfaceRF, WDM, optical power: +2~-15dBm
Optical reflection loss: ≥45dB
Optical receiving wavelength: 1550±10nm
RF frequency range: 47~1000MHz
RF output impedance: 75Ω
RF output level: 78dBuV
AGC range: -13~+1dBm
MER: ≥32dB@-15dBm
POTS interfaceFXS, RJ11 connector
Support: G.711/G.723/G.726/G.729 codec
Support: T.30/T.38/G.711 Fax mode, DTMF Relay
Line testing according to GR-909
USBStandard USB2.0
LED11 LED, For Status of PWR、LOS、PON、LAN1、LAN2、2.4G、5.8G、Worn、Normal(CATV)
Push-Button2, For Function of Factory Reset and WPS
Operate ConditionTemperature: 0℃~+50℃
Humidity: 10%～90%（non-condensing）
Storing ConditionTemperature: -30℃~+60℃
Humidity: 10%~90%（non-condensing）
Power SupplyDC 12V/1A
Power Consumption≤6W
Dimension260mm×158mm×192mm（L×W×H）
Net Weight0.35Kg
