PRODUCT DETAIL

Support EPON/GPON mode and switch mode automatically

Support Route PPPoE/DHCP/Static IP and Bridge mode

Support IPv4/IPv6 dual mode

Support 2.4G WIFI and Multiple SSID

Support CATV interface for Video Service and remote control by Major OLT

Support LAN IP and DHCP Server configuration

Support Port Mapping and Loop-Detect

Support Firewall function and ACL function

Support IGMP Snooping/Proxy multicast feature

Specialized design for system breakdown prevention to maintain able system

Support TR069 Remote Configuration and maintenance


specification

Technical itemDetails
PON Interface1 GPON BOB（Bosa on Board）
Receiving sensitivity: ≤-28dBm
Transmitting optical power: +1~+4dBm
Transmission distance: 20KM
WavelengthTX: 1310nm, RX: 1490nm
Optical InterfaceSC/UPC Connector
Design SchemeRTL9602C+RTL8192FR BOB(RTL8290B)
FlashSPI Nor Flash 16MB
LAN Interface1×10/100/1000Mbps(GE) and 1×10/100Mbps(FE) auto adaptive Ethernet interfaces, Full/Half duplex, RJ45 connector
WirelessCompliant with IEEE802.11b/g/n
Operating frequency: 2.400-2.4835GHz
Support MIMO, rate up to 300Mbps
2T2R, 2 external 5dBi antenna
Support Multiple SSID
Channel: Auto
Modulation type: DSSS, CCK and OFDM
Encoding scheme: BPSK, QPSK, 16QAM and 64QAM
CATV InterfaceRF, WDM, optical power: +2~-15dBm
Optical reflection loss: ≥45dB
Optical receiving wavelength: 1550±10nm
RF frequency range: 47~1000MHz
RF output impedance: 75Ω
RF output level: 78dBuV
AGC range: -13~+1dBm
MER: ≥32dB@-15dBm
LED9 LED, For Status of WIFI、WPS、PWR、LOS、PON、LAN1~LAN2
Push-Button3, For Function of Reset, WLAN, WPS
Operating ConditionTemperature: 0℃~+50℃
Humidity: 10%～90%（non-condensing）
Storing ConditionTemperature: -30℃~+60℃
Humidity: 10%~90%（non-condensing）
Power SupplyDC 12V/1A
Power Consumption＜6W
Dimension180mm×107mm×28mm（L×W×H）
Net Weight0.24Kg
