PRODUCT DETAIL

Material: PC+ABS :wet-proof、water-proof、dust-proof、anti-aging, protection level up to IP65

Impact resistant :IK09

Metal accessories material：Stainless steel

Pass test: RoHs、CE、ISO9001

Strong environmental adaptability: -40～+85℃

Installation method：wall-mounted or poled-mounted or overhead structure

Accessories: Users' Manual*1+ Accessories Bag * 1+Pole Ring*2 (Option)

specification:

ItemParameters
Size ( L*W*H)135*193*47 MM
Installation Size88*178 MM
Fiber diameter125μm ( 652 & 657 )
Tight cladding diameter250μm & 900μm
Mode of applicationSingle mode & duplex mode
Into the largest cable diameter(mm)1 ports for cables from 8 to 15 mm
End-use temperature-40～+85℃
AdaptorSC or LC
Insertion loss≤0.15dB（1310nm & 1550nm）
output8 SC/LC
Max Capacity8 cores
