PRODUCT DETAIL
Optical Fiber
specification:
| Project | Specifications |
| Optical Fiber | G657A1 |
| Ф(mm) | 0.9/2.0/3.0 |
| Optical Cable | White/Hytrel、Yellow/PVC/Aramid fiber |
| Item | Details |
| Insertion Loss | IEC 61300-3-4 |
| Return Loss | IEC 61300-3-6 |
| UPC Radius of curvature | 10～25mm |
| APC Radius of curvature | 5～18mm |
| Apex off set | 0～60μm |
| Optical fiber depression | +50～-100 |
| APC Angle | 8±0.5° |
| Mechanical properties | Durability：500 times＜0.2dB |
| 3D | APC≥70% / UPC≥80% |
