PRODUCT DETAIL
Material: PC+ABS :wet-proof、water-proof、dust-proof、anti-aging, protection level up to IP65
Impact resistant :IK09
Metal accessories material:Stainless steel
Pass test: RoHs、CE、ISO9001
Strong environmental adaptability: -40~+85℃
Installation method:wall-mounted or poled-mounted or overhead structure
Accessories: Users' Manual*1+ Accessories Bag * 1+Pole Ring*2 (Option)
specification:
| Item | Parameters |
| Size (L*W*H) | 265*155*55 MM |
| Material | PC+ABS |
| Applicable Environment | Indoor/Outdoor |
| Installation | Wall mounting or Pole mounting or Hang |
| Cable Type | FTTH cable |
| Input cable diameter | 2 ports for cables from 8 to 15 mm |
| Drop cables dimensions | Flat cables: 24 ports with 2.0 x 3.0 mm |
| Operating temperature | -40~+85℃ |
| IP Protection Degree | 65 |
| Water proof Adapter type | SC/LC |
| Insertion Loss | ≤0.15dB(1310nm & 1550nm) |
| Port of transmission | 24 Fibers |
