PRODUCT DETAIL
product advantages:
Material: PC+ABS :wet-proof、water-proof、dust-proof、anti-aging, protection level up to IP65
Impact resistant :IK09
Metal accessories material:Stainless steel
Pass test: RoHs、CE、ISO9001
Strong environmental adaptability:
Installation method:wall-mounted or poled-mounted
Accessories: Users' Manual*1+ Key*1+Accessories Bag * 1
specification:
| Item | Parameters |
| Size ( L*W*H) | 215*225*54MM |
| Installation Size | 145*120 MM |
| Fiber diameter | 125μm ( 652 & 657 ) |
| Tight cladding diameter | 250μm & 900μm |
| Mode of application | Single mode & duplex mode |
| Into the largest cable diameter(mm) | ports for cables from 6 to 14 mm |
| Drop cables dimensions | Flat cables: 8 ports with 2.0 x 3.0 mm |
| End-use temperature | -40~+85℃ |
| Adaptor | SC Simpleax or LC Duplex |
| Insertion loss | ≤0.2dB(1310nm & 1550nm) |
| output | 8 SC/LC |
| Max Capacity | 8 cores |
